SPECIFICATIONS

CELLULAR NETWORK

Operating Band

TE FDD: B1/3/5/8
LTE TDD:B34/38/39/40/41

LTE FDD:B1/B3/B5/B8
LTE TDD:B34/B38/B39/B40/B41
GSM:900/1800MHZ

LTE FDD:B1/2/3/4/5/7/8/28
LTE TDD:B40

LTE FDD:B1/3/5/7/8/20/28
LTE TDD:B38/40/41

Communication RF Chip

OC9743-63

Device Memory

1MB

Phase Error

<17.5°

Maximum Output

23 ± 2 dBm

Maximum Frequency Error

±0.1 PPM

MAIN SPECIFICATIONS

CPU

SSC333E ARM Cortex-A7 Single Core

Main Frequency

1.0GHz

Memory

64MB

Flash

16MB

POSITIONING

Positioning Systems

GPS/BeiDou

Frequency

GPS 1575.42MHZ
BD 1561.098MHZ

GPS Chipset

UC6228

Sensitivity

-160dBm (Tracking)
-140dBm (Acquisition)

Location Accuracy

5m

TTFF

60S (Cold start)
10S (Hot start)

WORKING PARAMETERS

Device Protocol

JT/T808-2013、JT/T1078—2016

Operating Voltage

USB input DC5V / Original car power 9-36V

Operating Current

12V/150mA (static 12V/3mA)

Battery

No

Continuous Working Endurance Time

5 minutes after ACC is closed

Continuous Idle Endurance Time

5 minutes after ACC is closed

Blind Zone Track Point Storage Capacity

300

Waterproof and Dustproof Grade

IP66

Resolution

1920*1080（1080P）

Video Storage Bit Rate

7Mbps

Video Upload Bit Rate

512kbps~2Mbps adaptive

Storage Medium

Class 10 or above high-speed TF card*1

PHYSICAL

Dimensions

52.7mmx98mmx49mm

Weight

91g

RELIABILITIES

Operating Temperature

-30°C ~60°C

Operating Humidity

10 - 95%
